Engineering case of cold storage in the United States

        This cold storage project was constructed by Xiamen Jialiang Co., Ltd. in 2022. At present, 1 set of cold storage has been completed, and 3 sets are still under construction.


Engineering category: high temperature cold storage (constant temperature storage)

Project Address: Coffeyville, Mississippi, USA

        Customer profile: With the continuous expansion of the customer's company's business, according to the storage needs of its crops, our technicians finally decided to build 4 sets of cold storage.

        The total construction area of the completed 1 set of cold storage is 1204㎡ (1 set includes two cold storages ), the temperature is 15～21℃, and the design of five-sided cold storage is adopted.

        Among them, the outer dimensions of cold storage 1 are 29.3 meters (length) × 13.7 meters (width) × 3.7 meters (height), covering an area of 868 square meters.

        The outer dimensions of cold storage 2 are 18.3 meters (length) × 6.1 meters (width) × 3 meters (height), covering an area of 336 square meters. With the consent of the client, the following pictures are all project construction entity photos of the scene issued by our client.

Figure 1: High temperature cold storage 1 entity photo——

temperature is 15 ~ 21 ℃, area is 868 square meters, net height is 3.7 meters

Project Overview:

(1) The cold storage insulation board adopts polyurethane board with double-sided color steel plate of 100mm.

(2) Cold storage 1 uses 3 common walls to divide the space of 868 square meters into 3 independent spaces, and cold storage 2 uses 5 common walls to divide the space of 336 square meters into 6 independent spaces for cargo storage.

Figure 2: High temperature cold storage 2 physical photo ——

temperature is 15 ~ 21 ℃, area is 336 square meters, net height is 3 meters

(3) The cold storage right-opening doors are all 1.1m×1.8m sliding doors with no threshold, using 100mm double-sided color steel plates.

(4) The refrigeration equipment of the high-temperature cold storage adopts the Emerson Copeland full-hermetic scroll unit, which is suitable for the voltage of 440v/60hz/3ph.

(5) This high-temperature cold storage project in Xiamen Jialiang was constructed in August 2022. At present, 1 set of cold storage has been commissioned and accepted, and the customer is using it. The remaining 3 sets of cold storage are still under construction.

Xiamen Jialiang can provide you with services:

        As a professional refrigeration equipment Co., Ltd., Xiamen Jialiang integrates cold storage design, manufacturing, installation and commissioning, and technical support services. We will try our best to provide you with visual production services throughout the process.

(1) Timely docking. After you initiate an inquiry, our salesperson will connect with you in time and share relevant past cases of the project, keep in touch and reply as soon as possible.

(2) The design is clear. After understanding your needs, our designers will issue a 3D drawing of the project for reference, so that you can form a preliminary sensory impression of the project.

(3) Quotation matches demand. After negotiating with you to confirm the drawing, our team will make a specific quotation according to your project requirements.

(4) Visualization of the whole process. In order to make it easier for you to keep abreast of the progress of the project, we will provide you with a production cycle table, and take relevant pictures and videos at each production point in time to ensure the advancement of the entire process until the product is finally sealed and shipped.

(5) Perfect after-sales system. On the one hand, we will provide you with the installation layout diagram marked with the serial number. You can install it quickly and conveniently according to the serial number in the diagram. If you encounter any problems, we will also provide you with remote guidance. On the other hand, if you need us to help you with after-sales installation, we will also send professional engineers to serve you.

Figure 3: Example of installation layout of cold storage 1

          Relying on decades of successful experience in the refrigeration industry, our team will design and build ultra-energy-saving automatic cold storage for customers according to local conditions, and provide corresponding customized services to meet your needs to the greatest extent.
          Please choose us with confidence! If you need any cold room related equipment and parts, please go to our website www.coldroomjl.com to browse our various products, we will be committed to providing you with the best service!
